Motherboard Components
Connectors
1. Dedicated IPMI port+USB3.0 x 2(LAN1)
24. PCIE 74P SlimSAS Connector (SLIMSAS 7
removed on -LE SKU)
2. CPU SMBUS Header (HDR_2)
25. PCIE 74P SlimSAS Connector (SLIMSAS 5
removed on -LE SKU)
3. CPU SMBUS Header (HDR_1)
26. PCIE 74P SlimSAS Connector (SLIMSAS 4
removed on -LE SKU)
4. VGA + COM Port (VGA_COM1)
27. PCIE 74P SlimSAS Connector (SLIMSAS 3
removed on -LE SKU)
5. CPU SMBUS Header (HDR_3)
28. Power SMBUS Header (PJ1)
6. BCM5720 RJ45 LAN Connector (LAN2)
29. CPU_FAN (CPU_FAN)
7. BCM5720 RJ45 LAN Connector (LAN3)
30. PCIE/SATA 74P SLIMSAS Connector
(SLIMSAS2)
8. TYAN Module Header (DBG_HD1)
31. PCIE/SATA 74P SLIMSAS Connector
(SLIMSAS1)
9. Rear ID LED Button (ID LED_BTN1)
32. Front Fan_3 (SYS_FAN_3)
10. HDT Header (HDT1)
33. Front Fan_2 (SYS_FAN_2)
11. COM2 Header (COM2)
34. Front Fan_1 (SYS_FAN_1)
12. SATA Connector (SATA 3.0 signals)
7Pin+2Power(SATADOM2)
35. CPU SMBUS Header (HDR_5)
13. SATA Connector (SATA4)
36. CPU SMBUS Header(HDR_4)
14. SATA Connector (SATA3)
37. FAN Header (FAN_HD1)
15. RearFan_2 (SYS_FAN_5)
38. Front Panel Header (FPIO_2)
16. RearFan_1 (SYS_FAN_4)
39. PSMI Header (PSMI_HD1)
17. SATA Connector(SATA 3.0 signals)
7Pin+2Power (SATADOM1)
40. IPMB Header (IPMB1)
18. Vertical Type A USB Connector
(TYPEA_USB1)
41. 8-pin Power Connector (PW3)
19. FPB USB2.0/USB3.0*2 Header
(USB3_FPIO1)
42. CPLD JTAG Connector (JTAG1)
20. NGFF 32x80mm & 32x110mm M.2
Connector (NGFF2)
43. 8-pin Power Connector (PW2)
21. NGFF 32x80mm & 32x110mm M.2
Connector (NGFF1)
44. ATX Power Connector (24p)(PW1)
22. PCIE 74P SlimSAS Connector
(SLIMSAS 8 removed on -LE SKU)
45. Power Button (PWR_BTN1)
23. PCIE 74P SlimSAS Connector
(SLIMSAS 6 removed on -LE SKU)
46. Reset Button (COLD_RST_BTN1)
Jumpers
a. J1 NVMe or SATA Select (J9_13)
e. BMC CPU COM1 (RX) (J197)
b. J1 NVMe or SATA Select (J9_24)
f. BMC COM PORT2 (TX) (J191)
c. CMOS Clear Jumper (J194)
g. BMC COM PORT2 (RX) (J190)
d. BMC CPU COM1 (TX) (J193)
h. PC BEEP (J120)
I. System RESET (J192)
PCIE Slots
A OCP B Slot (OCP1_B)
C. PCIE3.0 Slot x24 （PESLOT1）
B. OCP B Slot (OCP1_A)
D. PCIE3.0 Slot x24 （PESLOT2）
