Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S8036 motherboard, based on the
Aspeed
®
AST2500 chipset. The S8036 is designed to support AMD
®
EPYC™ 7002
series Processor, and Up to 1,024GB RDIMM/ 4,096GB LRDIMM DDR4 2667 MHz
memory. Leveraging advanced technology from AMD
®
, the S8036 is capable of
offering scalable 32 and 64-bit computing, high-bandwidth memory design, and
lightning-fast PCI-E bus implementation.
The S8036 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provide the S8036 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can find
all the information on all TYAN
®
products as well as all the supporting documentation,
FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
S8036GM2NE Specifications
Processor
Q'ty / Socket Type
(1) AMD Socket SP3
Supported CPU Series
(1) AMD EPYC™ 7002 Series Processor
Thermal Design Power
(TDP) Wattage
Max up to 225W
Memory
Supported DIMM Qty
(16) DIMM slots
DIMM Type / Speed
DDR4 ECC RDIMM/RDIMM 3DS/LRDIMM/LRDIMM 3DS
3200
Capacity
Up to 1,024GB RDIMM/ 4,096GB LRDIMM
Memory channel
8 Channels per CPU
Memory voltage
1.2V
Expansion
Slots
PCI-E
(1) PCI-E Gen4 x 24 slot, (1) PCI-E Gen4 x 24 slot (w/x16
link; can be x24 link if OCP mezz. conn.B is not used.
Please contact with Tyan technical support for details.)
Recommended TYAN Riser
Card (PCI-E Gen3)
M7106-L24-3F, PCI-E x16 slot 2U riser card (left) ,M7106-
R24-3F, PCI-E x16 slot 2U riser card (right)
Recommended TYAN Riser
Card (PCI-E Gen4)
M8036-L24-3F, PCI-E x16 slot 2U riser card (left), M8036-
R24-3F, PCI-E x16 slot 2U riser card (right)
