TYAN S8036 - Page 5

http://www.tyan.com
5
Others:
(1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B)
or (1) PCI-E Gen3 x8 OCP 2.0 slot (conn.A)
LAN
Q'ty / Port
(2) GbE ports + (1) dedicated for IPMI
Controller
Broadcom BCM5720
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) SFF-8654 for (16) SATA ports
Controller
Direct from AMD CPU
Speed
6Gb/s
RAID
N/A
Additional
SATA
Connector
(2) SATA-DOM,(2) SATA
Controller
Marvell 9235
Speed
6Gb/s
RAID
N/A
NVMe
Connector (M.2)
(2) 22110/2280 (by PCI-E Gen3 interface)
Connector (Slim
SAS)
(8) SFF-8654 for (16) NVMe ports
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input
/Output
USB
(2) USB3.0 ports (at rear), (2) USB 2.0 ports (via
cable), (1) Type-A USB3.0 port
COM
(1) DB-9 COM Connector (at rear, COM1) + (1)
Header (COM2)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports, (1) Dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
Power
SSI 24-pin + 8-pin + 8-pin power connectors
TPM
(Optional)
TPM Support
Please refer to our TPM supported list.
System
Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU & memory & system
environment
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
LED
Fan fail LED indicator, Over temperature warning
indicator, Fan & PSU fail LED indicator
Others
Watchdog timer support
Server
Management
AST2500 iKVM Feature
24-bit high quality video compression, Supports
storage over IP and remote platform-flash, USB 2.0
