2.5 LED Definitions
BMC_HBLED
BMC Heart Beat LED
Pin
Signal
+
VDD_33_DUAL
-
N18131759
State
Description
OFF
OFF
The LED shuts off when
the BMC controller cannot
be detected or properly
initiated.
Blinking
Green
The LED blinks per
second to indicate that the
BMC controller is working
normally
LED4
P0_PROCHOT_LED
Pin
Signal
+
VDD_33_DUAL
-
N34667495
State
Description
OFF
OFF
HW Sensor status is
normal
ON
Red
HW Sensor status is
abnormal.
LED5
PWR_GOOD_LED
Pin
Signal
+
VDD_33_DUAL
-
N34667528
State
Description
OFF
OFF
System all power is not
OK;
ON
Green
System all power ok
LED7
RESET_LED
Pin
Signal
+
VDD_33_DUAL
-
N34667581
State
Description
OFF
OFF
The LED shuts off when
the BMC controller cannot
be detected or properly
initiated.
ON
Green
The LED lights up when
BMC was reset OK;
LED_M1
NGFF1_LED
Pin
Signal
+
VDD_33_RUN
-
NGFF1_LED_L
State
Description
OFF
OFF
The LED shuts off when
no NGFF1 SSD insert
Blinking
Green
The LED blinks when
SSD working;
