LED_M2
NGFF2_LED
Pin
Signal
+
VDD_33_RUN
-
NGFF2_LED_L
State
Description
OFF
OFF
The LED shuts off when
no NGFF2 SSD insert
Blinking
Green
The LED blinks when
SSD working;
HDD_LED3
HDD_ACT_LED
Pin
Signal
+
VDD_33_RUN
-
HDD_ACT_LED_N
State
Description
OFF
OFF
NGFF Active LED off
ON
Green
NGFF Active LED on
IPMI_LED2
On board BMC IPMI
ALERT LED
Pin
Signal
+
VDD_33_DUAL
-
BMC_HW_FAULT_N
State
Description
OFF
OFF
HW Sensor status is
normal
ON
ORG
HW Sensor status is
abnormal.
PSMI_LED1
PSU_ALERT_N LED
Pin
Signal
+
VDD_33_DUAL
-
N18825566
State
Description
OFF
OFF
PSU status is abnormal
ON
ORG
PSU status is normal
ID_LED2
ID_LED
Pin
Signal
+
VDD_33_DUAL
-
REAR_ID_LED_N
State
Description
OFF
OFF
Not ID
ON
BLUE
ID_LED
