TYAN S8036 - Software Specifications

http://www.tyan.com
8
environment
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
LED
Fan fail LED indicator, Over temperature warning
indicator, Fan & PSU fail LED indicator
Others
Watchdog timer support
Server
Management
AST2500 iKVM Feature
24-bit high quality video compression, Supports
storage over IP and remote platform-flash, USB 2.0
virtual hub
AST2500 IPMI Feature
IPMI 2.0 compliant baseboard management controller
(BMC), 10/100/1000 Mb/s MAC interface
BIOS
Brand / ROM size
AMI, 32MB
Feature
Hardware Monitor, SMBIOS 3.0/PnP/Wake on LAN,
Boot from USB device/PXE via LAN/Storage, Console
Redirection, ACPI 6.1, ACPI sleeping states S0, S5,
FAN speed control automatic
Physical
Dimension
Form Factor
EATX
Board Dimension
12" x 13" (305 x 330mm)
Regulation
FCC (SDoC)
Class A
CE (DoC)
Class A
Operating
Environment
Operating Temp.
10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp.
- 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating Humidity
90%, non-condensing at 35° C
RoHS
RoHS 6/6 Compliant
Yes
Operating
System
OS supported list
Please refer to our AVL support lists.
Package
Contains
Motherboard
(1) S8036 Motherboard
Manual
(1) Quick Installation Guide
I/O Shield
(1) I/O Shield
Cable (SATA)
(2) SATA signal cables
1.3 Software Specifications
For the latest AST2500 User’s Guide and OS (operation system) support, please
visit the Tyan’s Web site at http://www.tyan.com for the latest information
