Memory voltage
1.2V
Expansion
Slots
PCI-E
(1) PCI-E Gen4 x 24 slot, (1) PCI-E Gen4 x 24 slot
(w/x16 link; can be x24 link if OCP mezz. conn.A is
not used. Please contact with Tyan technical support
for details.)
Recommended TYAN Riser
Card (PCI-E Gen3)
M7106-L24-3F, PCI-E x16 slot 2U riser card
(left) ,M7106-R24-3F, PCI-E x16 slot 2U riser card
(right)
Recommended TYAN Riser
Card (PCI-E Gen4)
M8036-L24-3F, PCI-E x16 slot 2U riser card (left),
M8036-R24-3F, PCI-E x16 slot 2U riser card (right)
Others:
(1) PCI-E Gen3 x16 OCP 2.0 slot (conn.A+conn.B) or
(1) PCI-E Gen3 x8 OCP 2.0 slot (conn.A)
LAN
Q'ty / Port
(2) GbE ports + (1) dedicated for IPMI
Controller
Broadcom BCM5720
PHY
Realtek RTL8211E
Storage
SATA
Connector
(2) SFF-8654 for (16) SATA ports
Controller
Direct from AMD CPU
Speed
6Gb/s
RAID
N/A
Additional
SATA
Connector
(2) SATA-DOM,(2) SATA
Controller
Marvell 9235
Speed
6Gb/s
RAID
N/A
NVMe
Connector (M.2)
(2) 22110/2280 (by PCI-E Gen3 interface)
Graphic
Connector type
D-Sub 15-pin
Resolution
Up to 1920x1200
Chipset
Aspeed AST2500
Input
/Output
USB
(2) USB3.0 ports (via cable), (2) USB3.0 ports (at
rear), (1) Type-A USB3.0 port
COM
(1) DB-9 COM Connector (at rear, COM1) +
(1) Header (COM2)
VGA
(1) D-Sub 15-pin VGA port (at rear)
RJ-45
(2) GbE ports, (1) Dedicated for IPMI
Front Panel
(1) 2x12-pin SSI front panel header
Power
SSI 24-pin + 8-pin + 8-pin power connectors
TPM
(Optional)
TPM Support
Please refer to our TPM supported list.
System
Monitoring
Chipset
Aspeed AST2500
Fan
Total (6) 4-pin headers
Temperature
Monitors temperature for CPU & memory & system
