PCIE 74P SlimSAS Connector (SLIMSAS 8/7/6/5/4/3/2/1)
pin
net
pin
net
A1
GND
B1
GND
A2
NVME0_RX_N0
B2
NVME0_TX_N0
A3
NVME0_RX_P0
B3
NVME0_TX_P0
A4
GND
B4
GND
A5
NVME0_RX_N1
B5
NVME0_TX_N1
A6
NVME0_RX_P1
B6
NVME0_TX_P1
A7
GND
B7
GND
A8
NVME0_BP_TYPE
B8
NVME0_SCK
A9
NVME0_WAKE_L
B9
NVME0_SDA
A10
GND
B10
GND
A11
NVME0_PEREFCLK_DP
B11
NVME0_PERST_L
A12
NVME0_PEREFCLK_DN
B12
NVME0_PRSNT_L
A13
GND
B13
GND
A14
NVME0_RX_N2
B14
NVME0_TX_P2
A15
NVME0_RX_P2
B15
NVME0_TX_N2
A16
GND
B16
GND
A17
NVME0_RX_N3
B17
NVME0_TX_P3
A18
NVME0_RX_P3
B18
NVME0_TX_N3
A19
GND
B19
GND
A20
NVME1_RX_N0
B20
NVME1_TX_P0
A21
NVME1_RX_P0
B21
NVME1_TX_N0
A22
GND
B22
GND
A23
NVME1_RX_N1
B23
NVME1_TX_P1
A24
NVME1_RX_P1
B24
NVME1_TX_N1
A25
GND
B25
GND
A26
NVME1_BP_TYPE
B26
NVME1_SCK
A27
NVME1_WAKE_L
B27
NVME1_SDA
A28
GND
B28
GND
A29
NVME1_PEREFCLK_DP
B29
NVME1_PERST_L
A30
NVME1_PEREFCLK_DN
B30
NVME1_PRSNT_L
A31
GND
B31
GND
A32
NVME1_RX_N2
B32
NVME1_TX_P2
A33
NVME1_RX_P2
B33
NVME1_TX_N2
A34
GND
B34
GND
A35
NVME1_RX_N3
B35
NVME1_TX_N3
A36
NVME1_RX_P3
B36
NVME1_TX_P3
A37
GND
B37
GND
