56
Combo Link OCUL2&OCUL4
Combo Link OCUL2&OCUL4 Bifurcation
OCUL2:SATA/OCUL4:x8 / OCUL2:SATA/OCUL4:x4x4 /
OCUL2:x8/OCUL4:x8 / OCUL2:x8/OCUL4:x4x4 /
OCUL2:x4x4/OCUL4:x8 / OCUL2:x4x4/OCUL4:x4x4 /
x16:spanning OCUL2& OCUL4
Combo Link OCUL5&OCUL6
Combo Link OCUL5&OCUL6 Bifurcation
OCUL5:x8/OCUL6:x8 / OCUL5:x8/OCUL6:x4x4 /
OCUL5:x4x4/OCUL6:x8 / OCUL5:x4x4/OCUL6:x4x4 /
x16:spanning OCUL5& OCUL6
Combo Link OCUL7&OCUL8
Combo Link OCUL7&OCUL8 Bifurcation
OCUL7:x8/OCUL8:x8 / OCUL7:x8/OCUL8:x4x4 /
OCUL7:x4x4/OCUL8:x8 / OCUL7:x4x4/OCUL8:x4x4 /
x16:spanning OCUL7& OCUL8
OCP Slot Link Width Configuration
OCP Slot Link Width Configuration, Auto is detected by GPIO(x8x8/x16)
x8x8 / x16 / Auto
Riser-L Up Slot Link Width Configuration
Left Riser Up Slot Link Width Configuration, Auto is detected by GPIO(x8x8/x16)
x4x4x4x4 / x8x8 /x16 /Auto
Riser-L Down Slot Link Width Configution
Setting Pcie Slot Link Width
x4x4 / x8
Riser-R Middle Slot Link Width Configuration
Right Riser Middle Slot Link Width Configuration
x4x4x4x4 / x8x8 / x16 / Auto
Riser-R Down Slot Link Width Configuration
Setting Pcie Slot Link width
x4x4 / x8
NVMe OPROM Policy
Select the NVMe SSD OPROM Policy
Embeded OPROM / External OPROM / Auto
OCP Slot Link Speed
OnBoard PCIE Slot Link Speed Configuration.
Auto / Gen1(2.5 GT/s) / Gen2 (5 GT/s) / Gen3 (8 GT/s)
