TABLE D
DV-5
A RED-E CABINET DELUGE SYSTEMS
PART NUMBER SELECTION
Limited
Warranty
For warranty terms and conditions, visit
www.tyco-fire.com.
Ordering
Procedure
The following Part Numbers (P/N) are
provided for standard cabinets with
integral control panel, built-in automatic
air supply, for example, air compressor
and controls for dry pilot actuation, and
galvanized pipe, nipples, and fittings.
DV-5
a Red-E Cabinet with
Deluge System
Specify: Size (specify) DV-5
A Red-E
Cabinet with (specify actuation) system
trim, P/N (specify per Table D)
Note: Dry Pilot Actuation is provided
standard with a OL12516AC (1/6 HP)
Air Compressor and Auxiliary Air Tank
complete with one Model AMD-1 Air
Maintenance Device.
Special Order
The DV-5
A Red-E Cabinet can be pro-
vided as follows as part of a special
request cabinet configuration:
• Without the control panel
• Without built-in automatic air sup-
ply, for example, air compressor and
controls for dry pilot actuation
• With an optional air/nitrogen mainte-
nance device when ordered without
built-in automatic air supply for dry
pilot actuation
• With trim black pipe, nipples, and
fittings, as may be desired for AFFF
systems
• With special size air compressors
for dry pilot actuation as shown in
Table B
• With 50 Hz air compressors as
shown in Table C
• With seismic kit. Kit must be ordered
separately.
Valve Size Part No.
1 1/2 to 4 in. .............. 53-040-0-001
4 to 8 in. ................. 53-080-0-001
Options
The DV-5
A Red-E Cabinet can be pro-
vided with the following options:
• With sight flow gage (provides a
visual indication of flow through the
main drain)
• With extra capacity batteries
(12V up to 18Ah) for longer battery
time and/or systems with heavy
power requirements, for example,
numerous audible signaling devices
• With Class “A” initiating appliance
circuits
• This option permits the connection
of Class “A” style wiring to the initi-
ating zones
• With Class “A” indicating appliance
circuits
• This option permits the connection
of Class “A” style wiring to the indi-
cating zones
• With auxiliary relay modules to
provide extra dry contacts when
required; up to an 8 ARM-44 module
per cabinet can be added
• With RA-4410 RC Remote
Annunciator
Contact Red-E Cabinet Technical
Support for information about special
request cabinet configurations.
P/N 53 — X —X — XX — X — X — X — X
1. Deluge Remote-Resetting, Pressure-Reducing available in sizes
3 to 8 in. (DN80 to DN200).
2. Air Maintenance Device does not apply (select “0” - None) when a
Compressor (1-8) is selected.
3. Black trim types are available only on request. Contact Red-E
Cabinet Technical Support for information.
4. A 50 Hz compressor model is available on request, select the
equivalent horsepower rating (1-8).
Size
in.
1 1 1/2
2 2
3 3
4 4
6
6
(168,3 mm)
8 8
System
Type
01 Deluge Wet Pilot Actuation
02 Deluge Dry Pilot Actuation
03 Deluge Electric Actuation
04 Deluge Remote-Resetting
05
Deluge Remote-Resetting
Pressure-Reducing
1
Trim
Type
3
1 NPT Galvanized
Control
Panel
0 None
A Included
Compressor
2,4
0 None
1 1/6 hp 125 Gal
2 1/3 hp 250 Gal
3 1/2 hp 365 Gal
4 3/4 hp 430 Gal
5 1 hp 615 Gal
6 1 1/2 hp 915 Gal
7 2 hp 1225 Gal*
* Requires 230V/60Hz
Air Maintenance
Device
2
0 None
1 AMD-1
2 AMD-2
3 AMD-3
Solenoid Pressure Rating
0 300 psi solenoid (standard)
TFP1301
Page 7 of 8

Tyco DV-5A Specifications

General
