Tyco SW-20 User Manual

TFP230
Page 2 of 6
Operation
The glass bulb contains a fluid that
expands when exposed to heat. When
the rated temperature is reached, the
fluid expands sufficiently to shatter the
glass bulb, allowing the sprinkler to
activate and water to flow.
**
*
*
*
**
1/2" (12,7 mm)
NOMINAL
MAKE-IN
WRENCH
FLAT
2-3/8"
(60,3 mm)
2"
(50,8 mm)
3/4"
NPT
3/4"
(19,1 mm)
CENTERLINE
OF SPRINKLER
WATERWAY
Temperature rating is
indicated on Deector.
Pipe thread
connections per ISO
7-1 can be provided
on special request.
6
4
3
2 1
5
TOP
-
Button
Deector
Compression Screw
Bulb
-
-
-
Components:
Frame
-
6
3
4
1
2
Sealing Assembly
-
5
1/2"
(12,7 mm)
*
**
*
*
**
1/2" (12,7 mm)
NOMINAL
MAKE-IN
WRENCH
FLAT
2-3/8"
(60,3 mm)
2"
(50,8 mm)
3/4"
NPT
3/4"
(19,1 mm)
9/16"
(14,3 mm)
CENTERLINE
OF SPRINKLER
WATERWAY
6
1
5
2
TOP
4
3
Sealing Assembly
Frame
Components:
Bulb
Compression Screw
Deector
Button
5
-
6
-
2
1
4
3
-
-
-
-
Temperature rating is
indicated on Deector.
Pipe thread
connections per ISO
7-1 can be provided
on special request.
6" (152,4 mm)
TO 12" (304,8 mm)
CEILING TO TOP
OF SPRINKLER
DEFLECTOR
DISTANCE
4/12
SLOPE
MAXIMUM
MAXIMUM
THROW
APPLY
WRENCH AS
SHOWN
WRENCH
RECESS
(END "B")
FIGURE 2
MODEL SW-24 (TY5337)
EXTENDED COVERAGE ORDINARY HAZARD
HORIZONTAL SIDEWALL SPRINKLER
11.2 K-FACTOR, 3/4 INCH NPT
FIGURE 4
SPRINKLER PLACEMENT
UNDER SLOPED CEILINGS IN
LOADING DOCKS
FIGURE 1
MODEL SW-20 (TY5332)
EXTENDED COVERAGE ORDINARY HAZARD
HORIZONTAL SIDEWALL SPRINKLER
11.2 K-FACTOR, 3/4 INCH NPT
FIGURE 3
W-TYPE 3 SPRINKLER
WRENCH
