Tyco SW-20 User Manual

TFP230
Page 3 of 6
NOTES
1. Backwall (where sprinkler is located) by sidewall (length of throw).
2. Requirement is based on minimum ow in GPM from each sprinkler. The indicted residual pressures are based on the nominal K-factor.
3. The centerline of the sprinkler waterway is located below the deector as shown in Figures 1 and 2.
4. Minimum spacing is for lateral distance between sprinklers located along a single wall. Otherwise adjacent sprinklers (i.e., sidewall sprinklers on an adjacent wall, on an
opposite wall, or pendent sprinklers) must be located outside of the maximum listed protection area of the extended coverage sidewall sprinkler being utilized.
MODEL SW-20 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5332)
OH Group 1 (0.15 gpm/sq-ft)
Response
Rating
Coverage
Area
(1)
,
Ft x Ft (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft (m)
Standard 16 x 16 (4,9 x 4,9 38 (144) 11.5 (0,79) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 18 (4,9 x 5,5) 43 (163) 14.7 (1,01) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 20 (4,9 x 6,1) 48 (182) 18.4 (1,27) 6 to 12 (150 to 300) 155, 200 8 (2,4)
MODEL SW-20 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5332)
OH Group 2 (0.20 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft x Ft (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft (m)
Standard 16 x 16 (4,9 x 4,9 51 (193) 20.7 (1,43) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 18 (4,9 x 5,5) 58 (220) 26.8 (1,85) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 20 (4,9 x 6,1) 64 (242) 32.7 (2,25) 6 to 12 (150 to 300) 155, 200 8 (2,4)
MODEL SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5337)
OH Group 1 (0.15 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft x Ft (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft (m)
Standard 16 x 22 (4,9 x 6,7) 53 (200) 22.4 (1,54) 6 to 12 (150 to 300) 200 8 (2,4)
Standard 16 x 24 (4,9 x 7,3) 58 (220) 26.8 (1,85) 6 to 12 (150 to 300) 200 8 (2,4)
MODEL SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5337)
OH Group 2 (0.20 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft x Ft (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft (m)
Standard 16 x 22 (4,9 x 6,7) 71 (269) 40.2 (2,77) 6 to 12 (150 to 300) 200 8 (2,4)
Standard 16 x 24 (4,9 x 7,3) 77 (291) 47,3 (3,26) 6 to 12 (150 to 300) 200 8 (2,4)
TABLE A
UL AND C-UL LISTING COVERAGE AND FLOW RATE CRITERIA
