Tyco SW-20 User Manual

TFP230
Page 2 of 6
Operation
The glass bulb contains a uid that ex-
pands when exposed to heat. When the
rated temperature is reached, the uid
expands sufciently to shatter the glass
bulb, allowing the sprinkler to activate
and water to ow.
**
*
*
*
**
1/2" (12,7 mm)
NOMINAL
MAKE-IN
WRENCH
FLAT
2-3/8"
(60,3 mm)
2"
(50,8 mm)
3/4"
NPT
3/4"
(19,1 mm)
CENTERLINE
OF SPRINKLER
WATERWAY
Temperature rating is
indicated on Deector.
Pipe thread
connections per ISO
7-1 can be provided
on special request.
6
4
3
2 1
5
TOP
-
Button
Deector
Compression Screw
Bulb
-
-
-
Components:
Frame
-
6
3
4
1
2
Sealing Assembly
-
5
1/2"
(12,7 mm)
*
**
*
*
**
1/2" (12,7 mm)
NOMINAL
MAKE-IN
WRENCH
FLAT
2-3/8"
(60,3 mm)
2"
(50,8 mm)
3/4"
NPT
3/4"
(19,1 mm)
9/16"
(14,3 mm)
CENTERLINE
OF SPRINKLER
WATERWAY
6
1
5
2
TOP
4
3
Sealing Assembly
Frame
Components:
Bulb
Compression Screw
Deector
Button
5
-
6
-
2
1
4
3
-
-
-
-
Temperature rating is
indicated on Deector.
Pipe thread
connections per ISO
7-1 can be provided
on special request.
6" (152,4 mm)
TO 12" (304,8 mm)
CEILING TO TOP
OF SPRINKLER
DEFLECTOR
DISTANCE
4/12
SLOPE
MAXIMUM
MAXIMUM
THROW
APPLY
WRENCH AS
SHOWN
WRENCH
RECESS
(END "B")
FIGURE 2
MODEL SW-24 (TY5337)
EXTENDED COVERAGE ORDINARY HAZARD
HORIZONTAL SIDEWALL SPRINKLER
11.2 K-FACTOR, 3/4 INCH NPT
FIGURE 4
SPRINKLER PLACEMENT
UNDER SLOPED CEILINGS IN
LOADING DOCKS
FIGURE 1
MODEL SW-20 (TY5332)
EXTENDED COVERAGE ORDINARY HAZARD
HORIZONTAL SIDEWALL SPRINKLER
11.2 K-FACTOR, 3/4 INCH NPT
FIGURE 3
W-TYPE 3 SPRINKLER
WRENCH
