MODEL SW-20 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5332)
OH Group 1 (0.15 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft. x Ft. (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft. (m)
Standard 16 x 16 (4,9 x 4,9 38 (144) 11.5 (0,79) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 18 (4,9 x 5,5) 43 (163) 14.7 (1,01) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 20 (4,9 x 6,1) 48 (182) 18.4 (1,27) 6 to 12 (150 to 300) 155, 200 8 (2,4)
MODEL SW-20 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5332)
OH Group 2 (0.20 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft. x Ft. (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft. (m)
Standard 16 x 16 (4,9 x 4,9 51 (193) 20.7 (1,43) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 18 (4,9 x 5,5) 58 (220) 26.8 (1,85) 6 to 12 (150 to 300) 155, 200 8 (2,4)
Standard 16 x 20 (4,9 x 6,1) 64 (242) 32.7 (2,25) 6 to 12 (150 to 300) 155, 200 8 (2,4)
MODEL SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5337)
OH Group 1 (0.15 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft. x Ft. (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft. (m)
Standard 16 x 22 (4,9 x 6,7) 53 (200) 22.4 (1,54) 6 to 12 (150 to 300) 200 8 (2,4)
Standard 16 x 24 (4,9 x 7,3) 58 (220) 26.8 (1,85) 6 to 12 (150 to 300) 200 8 (2,4)
MODEL SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLER (TY5337)
OH Group 2 (0.20 gpm/sq.-ft.)
Response
Rating
Coverage
Area
(1)
,
Ft. x Ft. (m x m)
Minimum
Flow
(2)
,
GPM (LPM)
Minimum
Pressure
(2)
,
PSI (BAR)
Deflector-To-Ceiling
Distance
(3)
,
In. (mm)
Sprinkler
Temperature
Rating, °F
Minimum
Spacing
(4)
,
Ft. (m)
Standard 16 x 22 (4,9 x 6,7) 71 (269) 40.2 (2,77) 6 to 12 (150 to 300) 200 8 (2,4)
Standard 16 x 24 (4,9 x 7,3) 77 (291) 47,3 (3,26) 6 to 12 (150 to 300) 200 8 (2,4)
NOTES
1. Backwall (where sprinkler is located) by sidewall (length of throw).
2. Requirement is based on minimum ow in GPM from each sprinkler. The indicted residual pressures are based on the
nominal K-factor.
3. The centerline of the sprinkler waterway is located below the deector as shown in Figures 1 and 2.
4. Minimum spacing is for lateral distance between sprinklers located along a single wall. Otherwise adjacent sprinklers (i.e.,
sidewall sprinklers on an adjacent wall, on an opposite wall, or pendent sprinklers) must be located outside of the maxi-
mum listed protection area of the extended coverage sidewall sprinkler being utilized.
TABLE A
UL AND C-UL LISTING COVERAGE AND FLOW RATE CRITERIA
