TFP230

Page 5 of 6

Ordering

Procedure

Contact your local distributor for avail-

ability. When placing an order, indicate

the full product name and Part Num-

bers (P/N).

Sprinkler Assemblies with NPT

Thread Connections:

Specify: Model (specify) ECOH Hori-

zontal Sidewall Sprinkler, SIN (specify),

(specify) temperature rating, (specify)

nish, P/N (specify from Table B)

Sprinkler Wrench:

Specify: W-Type 3 Sprinkler Wrench,

P/N 56-895-1-001

P/N 51 – XXX – X – XXX

SPRINKLER

TEMPERATURE

RATING

155

155°F (68°C)

(SW-20 Only)

200

200°F (93°C)

(SW-20 or SW-24)

SPRINKLER

FINISH

1 Natural Brass

Signal White (RAL9003)

Polyester

9 Chrome Plated

MODEL SIN

072 Model SW-20 TY5332

073 Model SW-24 TY5337

TABLE B

PART NUMBER SELECTION

MODEL SW-20 AND SW-24 ECOH HORIZONTAL SIDEWALL SPRINKLERS

WITH 3/4 INCH NPT CONNECTION
