10.2 VDR RS422 Output Sentence Structure
The C1714 VDR interface module sends various sentences to the VDR regarding the status of the panel. These
sentences are detailed in the following subsections.
A ‘fire status’ sentence is transmitted every 10 seconds, which shows the current number of zones in alarm
(number of zones can be 0 to 32). This is used primarily to indicate to the VDR that the Interface module is
connected & transmitting data.
When a fire, fault or isolation event occurs on a zone, the appropriate sentence is transmitted. The clearing of
the fire, fault or isolation is also transmitted unless the panel is reset, in which case zonal fire clear & zone fault
clear messages are not sent; only the RESET message is sent.
Each sentence consists of a number of data fields separated by a comma. A checksum of the transmitted data
is attached to the end of the sentence.
10.2.1 ZONAL FIRE Sentence Structure
This sentence takes the following form:
$ttfff,a,hhmmss.ss,bb,dd,eee,fff,g,h,cc*hh<CR><LF>
$ start of sentence
tt Talker Identifier = FR (Fire detection system)
fffSentence Formatter = FIR (Fire Detection)
,Field Separator
a Message Type = E (Event)
hhmmss.ss Time of event = VDROB has no clock so currently set to 000000
bbSystem indicator of fire detection = FD (Fire Detector)
ddDivision indicator of fire sensor allocation (1) = Zone Number Leave Blank
eeeDivision indicator of fire sensor allocation (2) = Loop Number Leave Blank
fffFire Detector Number = Leave Blank
gCondition = A (Activation) or V (Non-activation)
hAlarm’s acknowledge state = Leave Blank
c—cAlarm’s description text = Alarm description e.g. PANEL 01 ZONE 01 FIRE
*Indicates next two characters are the checksum
hhChecksum (XOR of all bytes including commas but excluding $ and *)
<CR> Carriage Return character = HEX 0D
<LF> Line Feed character = HEX 0A
A fire on zone 1 of panel 1 would generate the following sentence:
$FRFIR,E,000000,FD,,,,A,,PANEL 01 ZONE 01 FIRE*33<CR><LF>
The HEX data is:
24 46 52 46 49 52 2C 45 2C 30 30 30 30 30 30 2C 46 44 2C 2C 2C 2C 41 2C 2C 50
41 4E 45 4C 20 30 31 20 5A 4F 4E 45 20 30 31 20 46 49 52 45 2A 33 33 0D 0A
A fire cleared on zone 1 of panel 1 would generate the following sentence:
$FRFIR,E,000000,FD,,,,V,,PANEL 01 ZONE 01 FIRE CLEAR*5D<CR><LF>
The HEX data is:
24 46 52 46 49 52 2C 45 2C 30 30 30 30 30 30 2C 46 44 2C 2C 2C 2C 56 2C 2C 50
41 4E 45 4C 20 30 31 20 5A 4F 4E 45 20 30 31 20 46 49 52 45 20 43 4C 45 41 52
2A 35 44 0D 0A
NOTE: For a Machine Space zone, the description text includes ‘MS’ after the zone number e.g.
PANEL 01 ZONE 01 MS FIRE
