4.1.2 Replacement Part Order Codes and Descriptions
Tyco Part No.
Description
Used in
509.023.006 C1626 – 4-zone panel motherboard. With AC PSU
T1204A1
T1204A2
509.023.007
C1626 – 4-zone panel motherboard. With no PSU
T1204DC
509.023.008
C1627 – T1216-C panel motherboard
T1216-C
509.023.009
C1627 – T1232-C panel motherboard
T1232-C
509.023.012 C1626 – Repeater motherboard
T1216R-C
T1232R-C
509.023.021
C1628 – 4-zone panel display 2605041 fitted with 4 zone overlay
[No inserts]
T1204A1
T1204A2
T1204DC
509.023.022
C1628 – 16-zone panel display 2605043 fitted with 16 zone overlay
[No inserts]
T1216-C
509.023.023
C1629 – 32-zone panel display 2605044 fitted with 32 zone overlay
[No inserts]
T1232-C
509.023.031
C1628 – 16-zone repeater display 2605054 fitted with 16 zone overlay
[No inserts]
T1216R-C
509.023.032
C1629 – 32-zone repeater display 2605055 fitted with 32 zone overlay
[No inserts]
T1232R-C
2605061 C1631 – Repeater interface Board
T1216-C [with repeater]
T1232-C [with repeater]
T1216R-C
T1232R-C
2605060 C1630 – Output Expansion Interface Board
T1216-C
T1232-C
509.023.042
C1632 – 16-zone expansion board (provides zones 17 to 32)
T1232-C
2605064 C1634 Relay Output Board
T1216-C
T1232-C
508.023.035 C1665 – Muster interface (Optional add-on)
T1216-C
T1232-C
T1216R-C
T1232R-C
509.023.071 C1714 VDR Interface Board
T1216-C
T1232-C
509.023.052
24 VDC PSU [PS40-1-09]
T1204DC
509.023.051 110/230V AC PSU [PS136-1-09]
T1216-C
T1232-C
509.023.061
T1200/T1200-C Spare key set - 2 off access controls keys
All panels and repeaters
