3. Introduction
This document contains technical information
necessary for application design using the T1200-C
Marine Conventional Fire Detection control panel.
The following supporting documentation is also
available:
•  T1200-C

Sales Literature
•  T1200-C

User Manual
•  T1200-C

Installation and Commissioning Manual
•  T1200-C

Log Book
•  Display Insert Templates
Note: References are made throughout this
document to “Fire Protection Output” and “Fire
Output”. These refer to particular outputs from the
T1200-C  panels  and  are provided for specific
purposes:
•  Fire Protection Output: An output used to
activate ancillary fire protection equipment or
systems. For example, fire doors or  plant
shutdown.
•  Fire Output: An output used to send a common
fire warning signal to a remote fire monitoring
station.
References are also made to “Manual Fire Alarm”
and “Muster”. These  relate to fire alarm sounder
operating modes which are activated manually from
the fire panel display. The panel is configurable to
one or other of the two modes.
Detailed descriptions of both outputs are provided
within the following text.
4. General Description
The T1200-C Panel range is fully compliant with the
mandatory requirements and selected optional
requirements of EN54 parts 2 and 4 as well as the
relevant requirements of SOLAS 74.
The T1200-C

equipment range consists of the
following:
•  Panels: 4, 16 and 32 zone versions.
•  Repeater: 16 and 32 zone versions.
Each  panel in the range is housed in a metal
enclosure incorporating a door-mounted display
board fitted with a polyester overlay providing user
controls and indications. All display text is printed
on polyester inserts that slide into pockets in the
overlay. User controls are locked & unlocked via a
Keyswitch. All indications are implemented using
LEDs. The power supply is housed within the panel
enclosure and the standby batteries are housed in
a separate battery box.
Cable entry can be top or bottom. The T1204 has
gland plates at the top & the bottom. The T1216-C
& T1232-C  have only one gland plate but the
enclosure can be inverted to allow cable entry top
or bottom. Factory default is bottom cable entry for
the T1216-C & T1232-C.
4.1  Cabinet Specifications
Enclosure construction:
•  High quality, robust welded mild steel enclosure
with fully welded seams.
•  Lockable  door with trapped screws top &
bottom.
•  Gland plate with 20mm knock-outs.
•  Reversible door to allow enclosure to be
inverted to allow cable entry from top or bottom
(not T1204).
•  Door, gland plate and display plate fitted with
neoprene seals.
•  Display-mounted access control key switch fitted
with weatherproof cover.
•  Motherboard and power supply mounted to a
removable chassis for easy installation.
•  Optional door stay available.
Enclosure material gauge:
•  Enclosure – 1.6mm thick.
•  Gland plate – 2mm thick.
Paint finish:
•  High quality, durable 2 stage system.
•  Pre treatment –  Electro-zinc plated and full
passivation.
•  Polyester powder coat, semi gloss leatherette at
70-80 microns.
