1.3. Install wind speed sensor (Anemometer) (if required)
Push the wind cup into the shaft. as shown in figure 7.
Tighten the set screw with as shown in figure 8. Make sure the wind
speed cups spin freely.
Figure 7 Figure 8
1.4. Install Batteries
Make sure the solar panel is covered, then insert 2XAA batteries in
the battery compartment. The LED indicator on the back of the
transmitter will turn on for four seconds and normally flash once every
16 seconds (the sensor transmission update period).
Figure 9 Figure 10
