LXN5O508A
If the toe-in is not properly aligned, the
steering wheel may be uncontrollable or
the tractor may produce an abnormal vi-
bration. Measure the distance A and the
distance B of the front wheels and see if
the di erent between the two measure-
ments is 0.16 ~ 0.3 in (4~8 ㎜ ).
BR00O729A
If not, loosen nuts at the end of the cyl-
inder rod on both sides and adjust the
length of the screws. Tighten the nuts
when the toe-in is 0.16 ~ 0.3 in (4~8 ㎜ ).
Left and right adjustment of screw length
must be same.
2
1
