TYM BT400 - Control Operation

BACKHOE OPERATION
Do not dig near the stabilizers to avoid possible accident.
Boom and swing controls
Boom and swing controlsBoom and swing controls
Boom and swing controls
Bucket and crowd controls
Bucket and crowd controlsBucket and crowd controls
Bucket and crowd controls
Push the left hand outer control lever, boom moves down, and pull
back the lever, boom moves up. Also, pushing the lever fully
forward into the detent position, allows the boom to float. In the
float position, the boom can drift up or down without pressure.
Move the left hand outer control lever to the left, boom swings to
the left. Move lever right, backhoe boom swing moves to the right.
Push the right hand inner control lever, right stabilizer lowers. And pull up the lever, right stabilizer
raises.
Do not lift the tractor rear wheels by stabilizers. Also, be sure the stabilizers are seated on hard
ground to support. The backhoe/tractor.
- 14 -
Bucket and crowd controls
Bucket and crowd controlsBucket and crowd controls
Bucket and crowd controls
Push the right hand outer control lever, arm(dipperstick) moves
away from operator, and pull back the lever, arm(dipperstick)
moves toward the operator.
Move the right hand outer control lever to the left, bucket curls in.
Move lever right, bucket extends out from operator.
These
TheseThese
These two
twotwo
two levers
leverslevers
levers (
((
( Boom
BoomBoom
Boom and
andand
and swing
swingswing
swing control
controlcontrol
control lever,
lever,lever,
lever, Bucket
BucketBucket
Bucket and
andand
and crowd
crowdcrowd
crowd control
controlcontrol
control lever
leverlever
lever )
))
) provide
provideprovide
provide four
fourfour
four
simultaneous
simultaneoussimultaneous
simultaneous operations.
operations.operations.
operations. Both
BothBoth
Both experience
experienceexperience
experience and
andand
and practice
practicepractice
practice are
areare
are needed
neededneeded
needed to
toto
to eliminate
eliminateeliminate
eliminate excess
excessexcess
excess motion
motionmotion
motion
and increase operating efficiency.
and increase operating efficiency.and increase operating efficiency.
and increase operating efficiency.
