E
MAINTENANCE
E
25
(1) Body fuse box
Fuses are installed in this tractor to
prevent any possible accident in case of
wiring circuit malfunction.
If the electric system is malfunctioning
during driving, check for any blown fuse.
▶ CHECKING AND REPLACING
FUSE
1. Remove the cover of the fuse box.
2. Remove the blown fuse.
3. Fit a new fuse with the same
capacity.
4. The function and capacity of each
fuse are indicated on the cover of
the fuse box.
(2) Fuse
This tractor has 5 slow-blow fuses
installed to its wirings (1 for battery
positive terminal).
These fuses are blown to cut current to
the electric circuit in order to protect
wirings. Find the cause for blown fuses
and replace them with the specified
genuine parts.
If using fuses other than the specified,
wirings can be overheated, leading to a
fire.
Never use a fuse with different capacity.
Also, never use a steel wire or foil
instead of a fuse.
WARNING
BODY FUSE BOX
NORMAL OPEN CIRCLE
