15.DEVICELOCATIONCODES

FromtheProgrammingmenu,select“DeviceLocationCodes”tosetthelocationinthedwellingwhereeachinputdeviceislocated.
The8programmablelocationsperflatareenteredinthefollowingorder:

Intercom
Unit
Ceiling
Pullcord
Smoke
Detector
PIR
Detector
Input1
(LowTemp)
Input2
(DoorExit)
Input3
(Gas)
Input4
(CO)

Note;thelast4locations(I/P1‐4)areonlyavailableonintercomswithoutatelephoneconnected.





























DeviceLocationCodescanrangefrom00to99‐seelistbelow;

00 NotAssigned  20 Toilet(downstairs) 40 CommonRoom(main)
01 LocalUnit 21 Toilet(other) 41 CommonRoom(other)
02 Hallway(downstairs) 22 Kitchen(main) 42 Lift(main)
03 Hallway(upstairs) 23 Kitchen2 43 Lift2
04 Stairs(main) 24 KitchenArea(other) 44 Lift(other)
05 Stairs(2nd) 25 UtilityRoom(main) 45 FrontGate
06 Landing 26 UtilityRoom(other) 46 RearGate
07 Bedroom1(master) 27 Entrance/Lobby 47 Outbuilding(main)
08 Bedroom2 28 FrontDoor(main) 48 Shed
09 Bedroom3(other) 29 FrontDoor(other) 49 Outbuilding/Shed
10 Bedroom4(guest) 30 BackDoor(main) 50 Garden(front)
11 LivingRoom(main) 31 BackDoor(other) 51 Garden(rear)
12 LivingRoom2 32 Garage(main) 52 Garden(other)
13 LivingArea(other) 33 Garage(other) 53 Basement/Cellar
14 DiningRoom(main) 34 Workshop 54 GroundFloor
15 DiningRoom2 35 Laundry(main) 55 Bi nStore
16 DiningArea(other) 36 Laundry(other) 56 BoilerRoom
17 Bathroom(main) 37 Office(main) 57 Attic
18 Bathroom2 38 Study/Office(other) 58
19 Toilet(upstairs) 39 GamesRoom 59

LocationVoiceReporting;default=01foronsite/localoffsitespeechmessage.00todisable.

Click“Submit”toenteranychanges.



