3.TOENTER/EXITPROGRAMMODE

ToEnterAdventxtProgrammingMode

ConnectaLaptopPC(withaSLIPinterfaceset‐up)tothemainCPUlocalprogrammingportCON1usingaserialdatacable(Tynetec
P/No.EH0190).
DoubleclickontheInternetExplorericon.
MakesuretheSLIPConnectionisselectedintheDial‐upConnectionwindowandthenclickonConnect.

Themainprogrammingwindowwillopenasbelow;



ClickontheSystemmenuandrecorddetailsabouttheinstallationandmaintenancecompany.

ClickontheProgrammingmenuandselectthemoderequiredfromthelist.

ClickontheDiagnosticsmenutoviewdetailsofallcalls.

ToExitAdvent
xtProgrammingMode

CloseInternetExplorerbyclickingonthecrossinthetoprightcorner.
Ifadisconnectionboxappearsclickon“disconnect”otherwiserightclickontheconnectioniconinthetaskbarandclickondisconnect.
UnplugtheserialdatacablefromtheAdventxtcontrollerandtestthesystem.




















