TwohardwiredinputdevicescanbeconnectedtotheReach.PIR’smusthavenormallyclosedclean
contactswhichopenonalarmwhereasallotherinputdevicesmusthavenormallyopencleancontacts
whichcloseonalarm.Theinputsareprogrammableforthedevicetypeanditslocationwithinthe
dwelling.Ahardwiredinputleadisrequired–orderTynetecPartNo.ZSA550.
TheReachunitmustbewallmountedwhenahardwiredinputleadisused.
Theconnectorcovercannotbefitted.
HardwiredInput1–selecttheinputdevicetypefromthelistandentertheparameternumbere.g.
#013;theunitwillannounce“Smoke”.ForunitssettoTTprotocolsimplypress#.Forunitssetto
BS8521protocolyoucansetthelocationofthedevicebyenteringthe2digitLocationCodefromthe
tablebelowfollowedby#.
Example;forasmokedetectorconnectedtohardwiredinput1inadownstairshallwayenter#01302#.
HardwiredInput2–selecttheinputdevicetypefromthelistandentertheparameternumber+100
e.g.#112;theunitwillannounce“Pullcord”.ForunitssettoTTprotocolsimply press#.Forunitssetto
BS8521protocolyoucansetthelocationofthedevicebyenteringthe2digitLocationCodefromthe
tablebelowfollowedby#.
Example;forapullcordconnectedtohardwiredinput2inabathroomenter#11217#.
00 NoLocation 12 LivingRoom2 24 KitchenArea 36 LaundryRoom2 48 Shed
01 LocalUnit 13 LivingArea 25 UtilityRoom1 37 Office 49 Outbuilding/Shed
02 HallwayDown 14 DiningRoom1 26 UtilityRoom2 38 Study 50 GardenFront
03 HallwayUp 15 DiningRoom2 27 Entrance/Lobby 39 GamesRoom 51 GardenRear
04 Stairs1 16 DiningArea 28 FrontDoor1 40 CommonRoom1 52 GardenOther
05 Stairs2 17 Bathroom1 29 FrontDoor2 41 CommonRoom2 53 Basement/Cellar
06 Landing 18 Bathroom2 30 RearDoor1 42 Lift1 54 GroundFloor
07 Bedroom1 19 WC/ToiletUp 31 RearDoor2 43 Lift2 55 BinStore
08 Bedroom2 20 WC/ToiletDown 32 Garage1 44 Lift3 56 BoilerRoom
09 Bedroom3 21 WC/ToiletOther 33 Garage2 45 FrontGate 57 Attic
10 Bedroom4 22 Kitchen1 34 Workshop 46 RearGate 58
11 LivingRoom1 23 Kitchen2 35 LaundryRoom1 47 Outbuilding 59
2.3.4IDENTITYSETTING
ProtocolType–checkwiththecontrolcentrewhichprotocoltypetheyuse.Enter#022;theunitwill
announce“ProtocolType”press0forTTor1forBS8521followedby#.
UnitIdentity–theuniqueIDnumberissuedbythecontrolcentretoidentifytheusersname,address
andpersonaldetails.Enter#024;theunitwillannounce“UnitID”,entertheIDnumber(maximum12
digits)followedby#.
Pre‐AlarmDelay–thetimeallowedforanemergencycalltobecancelled(bytheGREENbutton)
beforetheReachstartstodialthecontrolcentre.Enter#025;theunitwillannounce
“Pre‐AlarmDelay”,enterthedelayinseconds00(nodelay),04,08,12,16,etc.in4secondintervalsto
60maxfollowedby#.
