MAX-7 / NEO-7 / LEA-7 - Hardware Integration Manual
GPS.G7-HW-11006-1 Design
Page 36 of 55
Transistor Vishay Si1040X T2
Table 9: Recommended parts
3.5.1 Recommended GPS & GLONASS active antenna (A1)
Manufacturer Order No. Comments
Taoglas (www.taoglas.com) AA.160.301111 36*36*4 mm, 3-5V 30mA
Taoglas (
www.taoglas.com) AA.161.301111 36*36*3 mm, 1.8 to 5.5V / 10mA at 3V
Additional antenna Manufacturer: INPAQ, Hirschmann,
Allis Communications, 2J, Tallysman Wireless
Table 10: Recommend GPS & GLONASS active antenna (A1)
3.5.2 Recommended GPS & GLONASS passive patch antenna
Manufacturer Order No. Comments
Amotech (www.amotech.co.kr) B35-3556920-2J2 35x35x3 mm GPS+GLONASS
Amotech (www.amotech.co.kr) A25-4102920-2J3 25x25x4 mm GPS+GLONASS
Amotech (www.amotech.co.kr) A18-4135920-AMT04 18x18x4 mm GPS+GLONASS
Table 11: Recommend GPS & GLONASS passive patch antenna
3.5.3 Recommended GPS & GLONASS passive chip antenna
Manufacturer Order No. Comments
INPAQ (www.inpaq.com.tw) ACM4-5036-A1-CC-S 5.2 x 3.7 x 0.7 mm GPS+GLONASS
Table 12: Recommend GPS & GLONASS passive chip antenna
