2.2.3 Communication interfaces
A UART, SPI and DDC (I
2
C compatible) interface is available to communicate with a host on the UBX-G7020.
There is also a USB interface available on dedicated pins, see section 2.7.
The UART, SPI and DDC pins are supplied by and operate at VDD_IO voltage levels.
There are 4 pins (PIO6 to PIO9) to provide a UART, DDC and SPI interface for communication with a host CPU.
These 4 PIOs can be configured as either 1 x UART and 1 x DDC or a single SPI interface selectable by the PIO10
(D-SEL pin). Table 5 below provides the port mapping details.
If the SPI port is used for communication to a host CPU, there is the possibility to configure the UBX-G7020 so
that the UART is mapped to PIO15 and PIO16. Thus the UART can be used as a debug interface or a second
communication interface if needed. To remap the UART use the Low Level Configuration, see section 2.10.2 and
u-blox 7 Receiver Description including Protocol Specification [3].
PIO10 (D_SEL) = “high”
(left open)
PIO10 (D_SEL) = “Low”
(connected to GND)
PIO10 (D_SEL) = “Low”
(connected to GND) and
UART remapped
Table 5: Communication Interfaces overview
It is not possible to have both the DDC and SPI interfaces active simultaneously for communication with
a host.
For debugging purposes it is recommended to have a second interface independent from the
application available via test-points.
The optional remapped UART interface is not available in Safe Boot Mode, see section 2.2.6.
For each interface, a dedicated pin can be defined to indicate that data is ready to be transmitted. This Tx-ready
pin can be mapped to any unused PIO pin. Each Tx-ready pin is associated with a particular interface and cannot
be shared. If the nominated PIO has another function by default, it needs to be disabled before configuring the
Tx-ready signal to that PIO pin. For configuration of the Tx-ready feature see u-blox 7 Receiver Description
including Protocol Specification [3].
2.2.3.1 UART interface
A UART interface is available for serial communication to a host CPU. The UART interface supports configurable
data rates of which the default is 9600 baud. The signals levels are related to VDD_IO supply voltage. An
interface based on RS232 standard levels (+/- 7 V) can be realized using level shifter ICs such as the Maxim
MAX3232.
Hardware handshake signals and synchronous operation are not supported.
A signal change on the UART RX pin can also be used to wake up the receiver in Power Save Mode (see u-blox 7
Receiver Description including Protocol Specification [3].).
The UART can be permanently remapped by Low Level Configuration to PIO15 and PIO16, see section
2.10.2.
