UBX-G7020 - Hardware Integration Manual
Production
GPS.G7-HW-10003 Objective Specification Page 61 of 74
5.4 Production
In production the first operation is to configure the UBX-G7020 properly as outlined below:
Set the Low Level Configuration
Program Firmware (for designs with SQI flash and not running from ROM firmware)
Set the Functional Configuration
For details on how to set the configuration see section 2.10. Programming the SQI flash can be accomplished
using either u-center (the u-blox GPS/GNSS evaluation software) or via a firmware update utility. A flowchart
detailing the sequence for applying the configuration and programming the SQI flash is shown below in section
5.4.1.
When configured properly, the design has to be tested regarding its GPS/GNSS capability. See section 5.4.2.
Once running, monitoring of system parameters can be done via a PIO serial interface, see section 5.4.3.
