U-Line CLR2060 User Manual

17
Figure 15
7. Holding door upright with top of
door tilted forward, place hole of
door pivot plate on bottom hinge
screw pin (see Figure 16). Be
sure that the bosses on the
closers align with holes in hinge
and hinge plate.
8. Tilt top of door into position in top
hinge and install top hinge screw
pin.
9. Install plastic screw plugs
removed in Step 2 in old hinge
holes (3 each, top and bottom).
Figure 16
BOSS
CLRCO008
UL319
Body_UM.qxd 12/17/04 9:16 AM Page 17
