REFRIGERATION SYSTEMS
Normal Vapor/Compression Cycle Refrigeration
• Refrigerant is pumped from the compressor to the condenser as a high pressure, high temperature
vapor.
• As the refrigerant cools in the high pressure condenser, the vapor condenses to liquid. During this
phase change, a great amount of heat is rejected with the help of the condenser fan.
• The liquid then flows to the dryer where it is strained and filtered.
