2075DWRWC
30
Design
■
Features
■
Performance
2075DWRWC WIRING DIAGRAM
DWR038
TOP DRAWER
BOTTOM
DRAWER
(BLUE) 1
(BROWN) 2
(PURPLE) 3
(YELLOW) 4
(RED) 5
(BLACK W/YELLOW) 6
7
(BLACK) 8
(WHITE) 9
CONTROL BOARD
THERMISTORS
DISPLAY
BOARD
CONNECTOR
12345678910
TOP
LAMP
BOTTOM
LAMP
POWER CORD ASSEMBLY
GREEN
GROUND
BLACK-HOT
(SMOOTH)
BLACK-NEUTRAL
(RIBBED)
EMBRACO
WHITE
COMPRESSOR
OVERLOAD
BROWN
BLUE
PURPLE
COND
FAN
RELAY
BLACK CAPACITOR
BLACK
BLACK
WHITE
WHITE
WHITE
BOT
VALVE
TOP
VALVE
YELLOW
RED
BLACK
BLACK
WITH
YELLOW
