REPLACING MOLD AND HEATER
1. Remove ice maker assembly. Refer to REPLACING ICE MAKER ASSEMBLY.
2. Remove one stripper screw (1) and stripper (2).
3. Remove three face plate screws (3) and face plate.
4. Remove one screw (4) and detach limit switch from mold.
5. Detach heater leads (5).
6. Remove two screws (6) and mold from support housing.
7. To assemble, replace parts in reverse order.
8. Install the ice maker assembly.
1
2
6
5
4
5
3
3
DWR061
CO2075DWR
