UAZ 3303 - Page 18

18
Models of Automobiles ÓÀÇ
Description 3741, 3962, 3909, 37419, 39629, 3303 33039 33036, 39094,
2206 39099, 22069 39095
Maximum speed, km/h 110 117
1)
100 110 105
Models of Automobiles ÓÀÇ
Description 3741, 3962, 3909, 37419, 39629, 39099,
2206, 3303 22069, 33039, 33036
39094, 39095
1 2 3
ENGINE
Model 4178 4218
4-stroke, carburettor-type
Cylinder number four
Cylinder order in-line, vertical
Firing order 1-2-4-3
Cylinder bore, mm 92 100
Piston stroke, mm 92 92
Displacement, l 2.445 2.89
Compression ratio 7.0 7.0
Nominal power at crankshaft
speed of 66 s
-1
(4000 min
-1
) kW (hp):
to DIN 70020 57.4 (78) 63.2 (86)
1)
When the tyres ß-245-1 are installed, in service the maximum speed should be not more than 110 km/h.
