UAZ 3303 - Page 22

22
Cooling fluid density at 20 °Ñ, g/cm
3
:
ÎÆ-40 "Ëåíà" 1.075-1.085
ÎÆ-65 "Ëåíà" 1.085-1.100
Spark plug gap, mm 0.85
+0.15
Cooling fluid temperature
in cooling system, °Ñ 80-90
Free travel of clutch pedal, mm 35-55
Free travel of brake pedal, mm 5-14
Front wheel toe-in, mm 1.5-3.0
Maximum turning angle of front inner wheel, deg 26-27
Steering wheel play, deg, not more 10
1 2 3
Models of Automobiles ÓÀÇ
Tyre Inflation Pressure, kPA (kgf/cm
2
) 3741, 3962, 3909, 2206, 3303, 33036, 39094
37419 39629 39099 22069 33039 39095
front wheels:
ß-245-1 0.19(1.9) 0.19(1.9) 0.22(2.2) 0.20(2.0) 0.19(1.9) -
ßÈ-357À, Ê-151, Ê-152 0.23(2.3) 0.22(2.2) 0.24(2.4) 0.23(2.3) 0.22(2.2) -
Ê-153, ß-435À 0.23(2.3) 0.22(2.2) 0.24(2.4) 0.23(2.3) 0.22(2.2) 0.25(2.5)
rear wheels:
ß-245-1 0.23(2.3) 0.19(1.9) 0.23(2.3) 0.24(2.4) 0.23(2.3) -
ßÈ-357À, Ê-151, Ê-152 0.25(2.5) 0.22(2.2) 0.25(2.5) 0.25(2.5) 0.25(2.5) -
Ê-153, ß-435À 0.25(2.5) 0.22(2.2) 0.25(2.5) 0.25(2.5) 0.25(2.5) 0.28(2.8)
