96
4. Gearbox control linkage 3 Lubricate through grease fittings
7. Steering rod joints 4 Lubricate through grease fitting
until it shows up from under
upper seal washers
8. Steering knuckle joints 2 Wash joints and pack 500 g of
grease
9. Steering knuckle kingpins 2 Every 32000 km of run Lubricate through grease fitting
of upper kingpin
11. Clutch release bearing 1 Pack grease cup to capacity
15. Parking brake 2 Clean of dirt before lubricating
expander and adjuster
mechanisms
16. Towing gear 1 Lubricate through grease fitting.
Lubricate latch and pawl axles
as required
26. Front and rear wheel 4 Grease layer in bearings should
hub bearings be 10-15 mm thick.
Space between rollers should be
filled up completely.
1234 5 6
Grease "Ëèòîë-24"
Grease "Ëèòà"
Grease "Ëèòîë-24ÐÊ"
