Ubee Interactive Using the Primary Network Option
Ubee DVW32CB Advanced Wireless Voice Gateway Subscriber User Guide • January 2015 76
9.3 Using the Primary Network Option
Use the Primary Network option to configure a variety of wireless security settings.
To configure wireless security options:
1. Click Wireless from the main menu.
2. Click Primary Network from the left side menu. Field descriptions are listed below the
screen example. This example shows the settings when the DVW32CB is in the
2.4GHz band.
Wireless default values are discussed in Understanding Default Values and Logins on
page 8.
Mode Displays the mode of the wireless access point: Possible
modes are:
Master – Communicates with associated wireless cards
that are in managed mode. Appears as a normal access
point with an SSID and channel. Network
communications, such as authentication, conflict, and
duplicate packets are managed by the wireless card.
Managed – Communicates with an associated master,
not directly with another managed AP. Wireless cards
connect to the master network and change their channel
to match. The master must accept the credentials of the
managed network for it to be associated.
Ad-hoc – Communicates directly with another wireless
network. Network cards must be in range and use the
same name and channel.
Monitor – Communicates in observation mode and does
not transmit. Can be used for troubleshooting wireless
links or checking bandwidth usage in the area.
PHY Mode Displays the physical transceivers (PHY) layer method used.
RSSI Displays the received signal strength (RSSI) of the wireless
access points in range of the device. Lower negative numbers
(for example, -1 to -65) indicate the access point is closer.
Greater negative numbers (for example, -66 to -95) indicate
the access point is farther away.
Channel Displays the channel on which the DVW32CB is operating.
BSSID Displays the MAC address for the nearby wireless access
points.
Label Description
