Ubee Interactive Using the Advanced Settings Options
Ubee UBC1303AB00 Advanced Wireless Voice Gateway Subscriber User Guide • June 2017 61
Source: Wikipedia.org, and IEEE article IEEE 802.11n-2009
5GHz Channels
The following table shows the 5GHz channel list and the corresponding frequencies.
6.4 Using the Advanced Settings Options
Advanced options provide many settings to configure your UBC1303AB00.
To view Advanced Settings options:
1. Click Gateway from the main menu.
2. Click Advanced Settings on the left side menu.
3. The following sub-menus are available for selection:
Using the Options option on page 62
Using the Firewall option on page 63
Using the IP Filter Option on page 64
Using the MAC PassThrough Option on page 65
Using the MAC Filter Option on page 66
Channel GHz Channel GHz
36 5.180 108 5.540
40 5.200 112 5.560
44 5.220. 116 5.580
48 5.240 136 5.680
52 5.260 140 5.700
56 5.280 149 5.745
60 5.300 153 5.765
64 5.320 157 5.785
100 5.500 161 5.805
104 5.520 165 5.825
