Installation in a sliding sash window
1. Cut the foam seal A (adhesive type) to the proper
length and attach it to the window frame. See Fig.12.
2. Attach the window slider kit to the windowsill.
Adjust the length of the window slider kit according
to the height
of window, shorten the adjustable window
kit if the height of window is less than 26.6 inches.
Open the window sash and place the window slider
kit on the windowsill. See Fig.13.
3. Cut the foam seal (adhesive type) to the proper
length and attach it o
n the top of the window
kit.
See Fig.14.
4. Close the sliding sash securely against the window
kit.
5. Cut the foam seal
(non-adhesive type)
(non-adhesive type)
to an
appropriate length and seal the open gap
between the window sash and
outer window sash. See Fig.15.
Foam seal
Foam seal A
(adhesive type)
Window
panel
Fig.12
Fig. 13
Fig.14
Fig.15
INSTALLATION INSTRUCTIONS (optional)
26.6
~
closed side
10
73.7
