Exhaust hose installation:
The exhaust hose and adaptor must be installed or removed
in accordance with the installation of the unit.
The duct can be compressed or extended moderately
according to the installation requirements, but it is
preferable to keep the duct length to a minimum.
IMPORTANT:
DO NOT OVER BEND THE DUCT (SEE Fig.
Fig.17
Note:
Cover the hole using the adaptor cap when not in use.
Fig.16
COOL or AUTO mode
FAN
DEHUMIDIFY
or mode
Install
Remove
Fig
.
18
1. Install the window exhaust adaptor B onto the exhaust
hose as shown in Fig.1 Refer to the previous
pages for window kit installation.
2. Push theexhaust hose into the air outlet opening along the
the arrow direction(See Fig.1
6.
7).
18)
INSTALLATION INSTRUCTIONS (optional)
11
