NEO-F10N-Integration manual
1 System description
This document is an important source of information for all aspects of NEO-F10N software
and hardware design. The purpose of this document is to provide guidelines for a successful
integration of the receiver with the customer's end product.
1.1 Overview
The NEO-F10N module features the u-blox F10 GNSS multi-band platform and provides exceptional
sensitivity and acquisition time with unparalleled low power consumption for L1 and L5 GNSS
signals.
1.2 Architecture
The NEO-F10N receiver provides all the necessary RF and baseband processing to enable dual-band
operation. The block diagram below shows the key functionality.
1.2.1 Block diagram
Figure 1: NEO-F10N block diagram
UBXDOC-963802114-12193 - R02
1 System description Page 5 of 42
C1-Public
