Table 19 lists some examples of possible internal off-board PCB-type cellular antennas with cable and
connector.
LTE FPC antenna with coax feed
617..960 MHz, 1710..2690 MHz, 3400..3900 MHz
115.8 x 30.4 mm
LTE wideband flex antenna
617..960 MHz, 1710..2690 MHz
130.0 x 30.0 mm
Cellular PCB antenna with cable and U.FL
698..960 MHz, 1575.42 MHz, 1710..2170 MHz, 2400..2690 MHz
96.0 x 21.0 mm
Flexible LTE antenna
689..875 MHz, 1710..2500 MHz
90.0 x 20.0 mm
Cellular antenna on flexible PCB with cable and U.FL
689..960 MHz, 1710..2170 MHz, 2300..2400 MHz, 2500..2690 MHz
110.0 x 20.0 mm
Cellular antenna on flexible PCB with cable and U.FL
698..960 MHz, 1710..2700 MHz
140.0 x 75.0 mm
Cellular PCB antenna with cable and U.FL
690..960 MHz, 1710..2170 MHz, 2500..2700 MHz
110.0 x 21.0 mm
Table 19: Examples of internal cellular antennas with cable and connector
Table 20 lists some examples of possible external cellular antennas.
Wideband LTE I-Bar adhesive antenna with cable and SMA(M)
617..960 MHz, 1710..2700 MHz, 4900..5850 MHz
176.5 x 59.2 x 13.6 mm
LTE terminal mount monopole antenna with 90° hinged SMA(M)
617..960 MHz, 1427..2170 MHz, 2300..2690 MHz
172.0 x 23.88 x 13 mm
Wideband LTE dipole terminal antenna hinged SMA(M)
617..1200 MHz, 1710..2700 MHz, 4900..5900 MHz
224 x 58 x 13 mm
Cellular screw-mount antenna with N-type(F)
698..960 MHz, 1710..2170 MHz, 2300..2700 MHz
83.8 x Ø 36.5 mm
Cellular ceiling-mount antenna with cable and N-type(F)
698..960 MHz, 1575.42 MHz, 1710..2700 MHz
86 x Ø 199 mm
Cellular pole-mount antenna with N-type(M)
698..960 MHz, 1710..2690 MHz
248 x Ø 24.5 mm
Multiband swivel dipole antenna with SMA(M)
617..960 MHz, 1400..2700 MHz, 3200..3900 MHz
223.24 x 56.13 x 10.97 mm
Table 20: Examples of external cellular antennas
