UCS C-SV 8A - Dimensions; Technical Data

Doc. 85588U - Rev. 22/10/2020
USER MANUALUSER MANUAL
ENEN
Drw. 32367/h10/54
6. TECHNICAL FEATURES
• ClassDcontrolpanel(controlpanelwithdetectors)accordingtoprEN12101-9:2008.
• Designedforuseinclass1environments,accordingtotheclassicaoncontainedinEN12101-10(clean,indoorenviron-
ments,temperature–5°Cto+40°C).
• Mainspowersupply(forsecondarypowersupply):100-250Vac,50–60Hz.Nominalpowerconsumpon:108W(C-SV4A)-
202W(C-SV8A).Standbypowerconsumpon:lessthan2W(C-SV4A)–lessthan9W(C-SV8A).
• Secondarypowersupplyfromleadbaeries:12V,4,5Ah,inseriesorleadbaeries:12V,4Ah,inseries.Maximuminterrup-
onmewhenswitchingbetweenthetwopowersupplysources:0,2s.
• Maximumcurrentrequiredofthebaeries,whentheprimarypowersupplyisunavailable:4,05Aor8,05Adependingon
the version.
• Motoroutputs:24Vdc+/-25%.2lines–max2Aor4AeachforC-SV4AandC-SV8Arespecvely.
• Visualsignals:n°3LEDs:GREEN,YELLOW,RED,onboard,fordiagnoscs.

• N°2X24Vdcpolarityinversionmotoroutputs,eachwithamaximumloadof2Aor4AforC-SV4AandC-SV8Arespecvely.2
naturalvenlaonzones,1smokeextraconzone.
• N°1x24Vdcauxiliaryoutput.Thisoutputisdisconnectedautomacallyifablackoutoranemergencyoccurs.Instandbymode,
youmustsubtractthepowerconsumponofthisoutputfromtheavailablepoweronthetwomotoroutputs.
• N°1outputwithclean(NC/NO)switchingcontact,todisplayemergencies(EM.SIG.).
• N°1outputwithclean(NC/NO)switchingcontact,todisplayemergencyclosing(EM.CL.SIG.);
• N°1outputwithclean(NC/NO)switchingcontact,todisplayanomalies/faults(AUX.SIG.).

• Inputforsmokesensors(upto10sensors).
• Inputforemergencypushbuons(upto10pushbuons).
• Inputforemergencysignalfromanyexternalalarmsystem.
• Inputforemergencyclosingcommand.
• AUX1inputdrivenbyanexternalvoltage(24Vdc+/-25%)fortheacvaonofEMERGENCYINTERLOCKcommand(bydefault,
theinputisdisabled).
• 2inputsformanualcontrolofthe2naturalvenlaonzones.
• Thermostatinput,1weathermanagementzone.
• Inputsforwind,rainandCO2sensors,1weathermanagementzone.
• Inputfordisablingweatherfuncons(thermostat,wind,rain,CO2).
ITEMS INCLUDED:
• 2leadbaeries:12V,4,5Ah(*)or2leadbaeries:12V,4Ah(*)(LxHxD:mm.90x100x70–Code40911V);
• Extractableinput/outputconnectorsforeasywiring.

Chargingme:for100%dischargedbaeries,maximum10hours.
 
6.1 Dimensions
WARNINGWARNING
