UCS C-SV 8A - Installation; Control Panel Positioning

Doc. 85588U - Rev. 22/10/2020
USER MANUALUSER MANUAL
ENEN
Drw. 32367/h11/54
7. INSTALLATION
7.1 Control panel positioning
3
4


Remove earth cable “A” placed on the
control unit door.
Mark on the wall the position of the
fixingholes.
Drillthewallandxthebox.
Choose adequately the xing system
accordingtothewalltypetowhichthe
controlunitisxed.
Remove plate “B”frombox“C”togainaccesstothexingholes.



For C-SVIB4A/8A version,disconnectconnectors“D”ofthepushbuon
panelandemergencypushbuonpanel.
WARNINGWARNING
1
A
2


B
C
C
D
B
