8.2 Initial configuration


In INTERLOCK SLAVEmode,AUX1inputisenabledwithemergencyinterlockfunconandEMCLSIGoutputbehavesasa
copyofEMSIG,sothatthecontrolunithastwoseparateemergencysignals(seediagram10onpage53).
In INTERLOCK MASTERmode,themotoroutput2isusedasanemergencyinterlockcommandtotheothercontrolunits
thatareinINTERLOCKSLAVEmode.Therefore,theoutput2isacvatedonlyintheemergencystatus(allthefunconsof
naturalvenlaonaredisabledforzone2)andithasalwaysthesamepolarity(theonecorrespondingtotheopening)(see
wiring10onpage53).
When a fault occurs, the control unit can be interrogated using a diagnoscs cable (code
41853M),whichcanbeconnectedtoaPCandmakesitpossibletorecoverinformaononthe
controlunit’sstatusinreal-me.
Tousethediagnoscscable,seethespecicmanual.
Thecontrolunitconguraonmustbecarriedoutbymeansofdip-switchesandwindsensorpotenometerposionedonthe
board.
Posiondip-switchesandwindthresholdaccordingtothedesiredconguraon.
OFF:actuatorsdriving
OFF:naturalvenlaonbuonsin“dead-
man”mode
OFF: automacclosingonlyincaseof
doubleresengclosetogether
OFF: INTERLOCKSLAVEmodedisabling
OFF: INTERLOCKMASTERmodedisabling
ON: solenoids/electromagnetsdriving
ON: momentaryoperaon
ON: automacclosingaersinglereset
ON: INTERLOCKSLAVEmodeenabling
ON: INTERLOCKMASTERmodeenabling
OFF:repeonofemergencyopencom-
mandinacve(deadlockinacve)
ON: repeonofemergencyopencommand
acve(deadlockacve)
1 2 3 4 5 76 8
ON
NOT USED
NOT USED
NOT USED
NOT USED
