UCS C-SV 8A - Page 16

Doc. 85588U - Rev. 22/10/2020
USER MANUALUSER MANUAL
ENEN
Drw. 32367/h16/54
OnthepushbuonpanelandonthecontrolunittherearethreeLEDs-Green,Yellow,andRed-whichworkaccordingtothe
followinglogic:
Logicappliedforthe:
 emergency(openingorclosing,indierently):   ONFIXED
 emergencyinterlock(seepar.8.3.5)    ONFLASHING
 allothercases:       OFF
Logicappliedforthe:
fault ON FIXED
power supply problems ON SINGLE FLASHING
 powersupplyproblems+fault     ONDOUBLEFLASHING
Logicappliedforthe:
 Nofault,primarypowersupplyOKandnoemergency  ONFIXED
all other cases OFF
Allthecombinaonsareindicatedbelow:
LED STATUS CONTROL UNIT STATUS
RED  GREEN




 Fault
No No No No
No No No Yes
x1
No No Yes No
x2
No No Yes Yes
x1
No Yes No No
x2
No Yes No Yes
x1
No Yes Yes No
x2
No Yes Yes Yes
Yes No No No
Yes No No Yes
x1
Yes No Yes No
x2
Yes No Yes Yes
x1
Yes Yes No No
x2
Yes Yes No Yes
x1
Yes Yes Yes No
x2
Yes Yes Yes Yes
x1
Interlock em. No No No
x1
Interlock em. No No Yes
x1 x1
Interlock em. No Yes No
x1 x2
Interlock em. No Yes Yes
x1 x1
Interlock em. Yes No No
x1 x2
Interlock em. Yes No Yes
x1 x1
Interlock em. Yes Yes No
x1 x2
Interlock em. Yes Yes Yes
- o - on -flashing
x1=Interlockemergencyx2=Emergencyclosing
Note
