Doc. 85588U - Rev. 22/10/2020
USER MANUALUSER MANUAL
ENEN
Drw. 32367/h8/54
Theinstallaonoftheemergencypushbuoniscompulsorybecause,inaddiontoallowingmanualemergencycontrol,italso
providesdisplayoffault/emergencywarnings,andcanbeusedforeasy,remoteRESETTING.
Forthewiringdiagrams,refertopagesfrom49to53.

Thecontrolunitcomeswith2baeriesthatarekeptchargedwhenthemainspowersupplyisavailableand,whenthisisnot
available,theyguaranteea72hourautonomyperiodinstand-bymode,makingitpossibletosllexecuteacompleteemergency
openingcommand,asprescribedbyEN12101-10.
Accessoriesandequipmentconnectedtothecontrolunitmustbechosenamongthoselistedinthefollowingtableanddiagram:
C-SV4A/8AandC-SVIB4A/8Acontrolunitscommandthesmokeandtheheatextraconincaseofreandalsotheyallowdaily
venlaonbyopeningasingleorseveralwindows.Dependingonthedesireduse,thecontrolunitcanbesuppliedin4and8Amp
versionsanditallowstheconneconofawiderangeofsensors,rodactuators,rackactuatorsandchainactuatorsanddierent
accessoriestocompletetheinstallaon.
Thecontrolunitsareequippedwithbuerbaeriesandtheycommand24Vdcactuators.Smokeextraconopeningoccursaer
theenablingofsmokedetectors,emergencypushbuons,recontrolunitsor“BMS-buildingmanagementsystem”systems.
TheemergencypushbuonsareequippedwithLEDsfordisplayingfaultsandmalfunconsofpowersupplyandemergencystatus.
Thecontrolunitalsoallowsnaturalvenlaonbycontrollingautomacallythewindowsdependingonenvironmentalcondions
detectedbythesensorsensuringcomfortandenergysaving.
Themanualcontrolofwindowsanddoorsoccursbymeansofspecicpushbuonsontwoseparateareas.
WARNINGWARNING
N.
   
1 Smokeopcalsensor 36418Q 10 pcs
2poles,sect.0,5-1,5sq.mm,
Lmax 500m
2 Emergencypushbuonpanel 42140N 10 pc
7poles,sect.0,5-1,5sq.mm,
Lmax 500m
3 Acouscsignallingdevice 40892C 1 pcs
2poles,sect.0,5-1,5sq.mm,
Lmax 500m
4
ConneconofBMSsystemor
third-partyreproteconsystem
- -
2poles,sect.0,5-1,5sq.mm,
Lmax 500m
5 Wind sensor WS 37185V 1 pc
2poles,sect.0,5-1,5sq.mm,
Lmax 500m
6 Rain sensor RS 40450K 1 pc
4poles,sect.0,5-1,5sq.mm,
Lmax 500m
7 CO2 sensor 41773L 1 pc
2poles,sect.0,5-1,5sq.mm,
Lmax 500m
8 Thermostat TH 40675K 1 pc
3poles,sect.0,5-1,5sq.mm,
Lmax 500m
9
Naturalvenlaonpushbuons
(2separateareas)
41019H
(orequivalent)
-
3poles,sect.0,5-1,5sq.mm,
Lmax 500m
10
Actuators24Vdc(2separatemotor
lines)
See UCS product
catalogue
Dependingonactuator
absorponandcontrol
unitsize
See par. 7.2 “Electrical
connecons”
11 C-SVsmokeextraconcontrolunit
See UCS product
catalogue
- -
WARNINGWARNING
