UEi ATTPC3 - AC;DC Low Amps Measurement

12
WARNING
• Do not attempt to measure more than 2000µA.
DC Low Amps (Test Lead Input)
Range Resolution Accuracy Overload Protection
400µA 0.01µA
± (1.2% +3 dgts) 2000µA/600V RMS
2000µA 0.1µA
AC Low Amps (Test Lead Input)
Range Resolution Accuracy Overload Protection
400µA 0.01µA ± (2.0% +5 dgts)
2000µA/600V RMS
2000µA 0.1µA ±(1.5% +5 dgts)
45Hz to 400Hz True RMS (crest factor <3:1)
AC/DC Low Amps: <2000µA
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
• Default =
• Press x1 =
µA
Features:
RANGE
µA
