UEi ATTPC3 - Operating Instructions; AC;DC Voltage Measurement

8
WARNING
• Use CATIII rated Test leads or higher.
• Do not attempt to measure more than 750V AC/1000V DC.
• Do not exceed 25 volts AC or DC – RMS at either the common or
Multifunction input ports as measured from earth ground.
AC Volts
Range Resolution Accuracy Overload Protection
400mV 0.1mV
± (2.0% +5 dgts) 750V RMS
4V 1mV
40V 10mV
400V 100mV
750V 1.0V
45Hz to 1kHz True RMS (crest factor <3:1)
DC Volts
Range Resolution Accuracy Overload Protection
400mV 0.1mV
± (0.5% +4 dgts)
1000V RMS
4V 1mV
40V 10mV
400V 0.1V
1000V 1V ± (0.8% + 10 dgts)
Hi-NCV-Lo
MFD
°F °C
µA
CAT Ill
600V 400A
MAX/MIN
HOLD
Hz / Duty
SELECT
TEMP
DISCONNECT
30V MAX
TESTLEADS
True RMS
DL389B
MAX
CATll1000V
CATIII600V
V
Features:
RANGE
AC/DC Voltage 750VAC/1000VDC
• Default =
• Press x1 =
