15
Test Lead Notes
CATIV 600V Measurement Locations
• Ensure the test lead shield is pressed firmly in place. Failure to use the CAT
IV shield increases arc-flash risk.
CATII 1000V Measurement Locations
• CAT IV shields may be removed for CAT II locations. This will allow testing
on recessed conductors such as standard wall outlets. Take care not to lose
the shields.
WARNING:
Test lead category protections apply only to test leads and
should not be confused with the meter’s specific CAT rating. Observe the
maximum category protection indicated on the meter the test leads are
plugged into.
4mm
18mm
Battery Replacement
•
When the batteries are too low for safe
operation, the Low Battery indicator will display.
• Loosen screw. Remove battery cover.
• Replace the old batteries with 2 new
(AAA) batteries.
• Replace the battery cover. Tighten the screw.
