UEi C161 User Manual

11
MENU
Using the Menu
The Menu position on the Rotary Dial allows for the customization of the default settings for the analyzer as per the user’s
requirements. Navigation through the Menu system is via the dedicated user’s interface buttons (Up, Down, Enter).
As you navigate up or down through the Menu, the items will scroll accordingly, eventually back to the beginning.
Rotate Selector Dial to MENU to set up or customize your settings.
Selected parameter are centered, highlighted with arrow icons on either side.
Use and buttons to scroll menu options,
Press to a select a parameter to edit. Press button to scroll fields to change .
Press and buttons to change field contents.
Press to enter content selected.
Menu Items
MENU Sub Menu OPTIONS/COMMENTS
Time
HH:MM:SS
24 Hour Format (e.g. 7AM = 0:00:00, 7PM = 19:00:00)
Date
DD/MM/YY
Header
LINE 1
Customer info displays on print outs
LINE 2
Customer info displays on print outs
EXIT
IR Print
KMIRP
Select to print to KMIRP
IRP-2
Select to print to IRP-2
Temperature Scale
˚C
Secet ˚F or ˚C.
˚F
Gas Unit
ppm
ppm(n)
mg/m3
mg/m3(n)
mg/kWh
mg/kWh(n)
Language
English
Espanaol
Francais
Effciency
Gross
Nett
O2 ref Used for "Normalized" readings. Default set to 3%, can be adjusted up or down.
Logs
VIEW
View current memory usage and view stored Logs
DELETE ALL
EXIT
Code Password protected for authorized service agents only/ LEAVE SET TO "0000".
STATUS
FLUE 1
AUX
FLUE 2
TEMP
C
o
m
b
u
s
t
i
o
n
A
n
a
l
y
z
e
r
C161
C
O
C
O
2
T
E
M
P
Menu Option to edit
